DVOP-IN-IR-EGB4-EG1-EM7-RC-SU M12 Connector Layer 3 industrial Ethernet switch: DVOP-IN-IR-EGB4-EG1-EM7-RC-SU series Shenzhen Guangxiang has fully intellectual property rights of the management of three layer industrial Ethernet Fibre Channel switches, the product is based on high-performance ASIC chip technology, adopts modular structure design, provides 7 10/100M Ethernet electrical ports with M12-D connectors, Five 10/100/1000M upstream Ethernet electrical ports using the M12-A port and one Console management port enable full-speed, non-blocking exchange and communication between seven 100-megabit electrical ports and five upstream electrical ports. It has rich network management functions such as 802.1Q VLAN, 802.1p QoS, IGMP static multicast, port aggregation, port mirroring, port configuration, RSTP, FR-Ring, access control, remote monitoring, port statistics, network diagnosis, etc. Supports Flow Control, 808.3ad, broadcast storm control, 802.1x authentication, port aggregation, stack, and mirroring. Supports IGMP Snooping, multicast filtering and unknown multicast discarding, static multicast groups, 4K multicast groups, and GMRP multicast. Supports dynamic DHCP address assignment, DHCP Snooping, binding based on MAC addresses, and shielding of unauthorized DHCP servers to implement ARP anti-spoofing and IP traffic control. Supports the VLAN function, supports 4K vlans that comply with IEEE 802.1Q standards, supports port-based vlans and protocol-based vlans, and supports GVRP dynamic vlans. All ports support non-blocking, full-line speed forwarding, providing you with strong data processing capabilities; Supports multiple management modes. Users can set various functions of the switch through various modes, such as Web, SNMP, and Telnet.

● 10/100/1000M electrical ports with five M12-A connectors, four of which support the BYPASS function. G1 and G3 form a Bypass group and G2 and G4 form a Bypass group to prevent communication interruption caused by power supply faults.

● 10/100M Ethernet electrical port with 7 M12-D connectors

● Supports IGMP Snooping (V1, V2, V3), multicast filtering and unknown multicast discarding, static multicast groups, 4K multicast groups, and GMRP;

● Support VLAN function, support 4K vlans compliant with IEEE 802.1Q standard, support port-based VLAN and protocol-based VLAN, support GVRP dynamic VLAN;

● Support dynamic DHCP address assignment, DHCP Snooping, binding based on MAC addresses, shielding of illegal DHCP servers, ARP anti-spoofing and IP traffic control.

● Support Flow Control, broadcast storm control, 802.1x authentication support, port aggregation, mirroring support, etc.

● Support QoS quality of service, support -IEEE802.1p/1Q and TOS/DiffServ;

● Full speed storage and forwarding

● Extremely wide operating temperature range, operating temperature up to -40℃ ~ 85 ℃ extremely wide temperature long-term stable operation.

● Support LLDP link discovery protocol, loop detection and alarm indication;

● Support network management SNMP function, can directly connect with the third-party network management, facilitate the establishment of the whole service network management system of the high-speed virtual toll site.

● Support IEEE 802.3, IEEE 802.3U, IEEE 802.3AB, IEEE 802.3AF, IEEE 802.3at, IEEE 802.3x, IEEE 802.1p, IEEE Standards such as 802.1Q, IEEE802.1d, and IEEE802.1w

SNMP-MIB support: MIB-II(RFC1213), Bridge MIB(RFC1493), RSTP MIB, RMON MIB(RFC1724) Group, etc

● The device supports STP, RSTP and other ring network redundancy protocols, and any two ports can be used to form a self-healing ring network and support multiple independent self-healing rings at the same time.

● Support industrial G.8032, ERPS and other industrial fast ring network self-healing protocol, self-healing time <50ms

● All network ports and power ports adopt advanced bridge self-healing multi-level lightning protection design, in line with EN61000-4-2~EN61000-4-6 series international protection standards.

● Electromagnetic compatibility in line with industrial level 4 standards, suitable for a variety of electromagnetic environment harsh occasions, MTBF≥100000h.

● Industrial fanless design, support redundant dual power supply 1+1 hot backup, support 110VAC/220VAC/48VDC cross redundancy backup.

● Support a variety of network management methods, such as: SNMP, Web browser, Telnet, Console and RS232 console management.

Product model	DVOP-IN-IR-EGB4-EG1-EM7-RC-SU
Basic Features
Fixed electrical ports	7 10/100M M12-D electrical ports,5 10/100/1000M M12-A electrical ports,
Console port	1
Processor	RISC 600MHz
Flash capacity	8MB
Memory capacity	64MB, up to 512MB
MAC address table	16K, address self-learning, support IEEE802.1D standard
VLAN	4096 vlans compliant with IEEE802.1Q standard, support port-based VLAN and protocol-based
Packet buffer	VLAN 12MB
Swap parameters	Priority queue :8, number of vlans :256, number of multicast groups :256, Minimum bandwidth Qos:32K, backplane bandwidth:128Gbps;
Product features
Spanning Trees	Support STP, RSTP, MSTP, ERPS Support PVST/PVST+
VLAN	Support for port-based vlans Mac-based vlans 802.1Q tagging VLAN is supported Super Vlan support Support for Private vlans Supports GVRP dynamic VLAN configuration Supports QinQ and flexible QinQ Voice VLAN support
Flow control	4K IEEE 802.1Q standard vlans are supported Standards-based IEEE 802.3x flow control Adopt IEEE 802.1Qbb priority to control flow CAR function supported
Broadcast control	Suppress the broadcast storm, reaching a critical point to stop sending
Multicast control	IGMP Snooping automatically monitors multicast packets and multicast vlans
Multicast routing	IGMP v1/v2/v3, MLDv2 PIM-SM,OLINK&PIM-DM DVMRP(Distance Vector Multipoint Broadcast Routing Protocol) GMRP(Multicast Dynamic Registration Protocol) 4K multicast groups
Port bundling	Each group has a maximum of 8 and supports 128 groups at the same time Dynamic LACP or static aggregation
Port mirroring	Traffic classification-based mirroring and port mirroring are supported
DHCP Features	Support DHCP Server, DHCP Client and DHCP relay, support DHCP Snooping, Yes MAC address-based The binding, which supports masking of illegal DHCP servers
NAT features	Supports static or dynamic NAT address translation
Security features	IEEE 802.1x port authentication, PKI authentication Port Security(Secure port) function Hardware support IP ACL,MACACL,VIan ACL The hardware supports port-based user IP+MAC+VIanID+ user account combination binding IP Source Guard is supported Support for WEB interface user authentication Remote RADIUS,TACACS+ authentication Hierarchical user management and password protection Shield Technology Security control technology Policy control List
Quality of service	IEEE 802.1Qau Congestion Mechanism 8 send queues per port map 8 priorities of 802.1p WRED,WFQ,SP and FIFO queue scheduling algorithms Best Effort Service (Best Effort Service) Differentiated Service Strict Priorty algorithm Weighted Round Robin (Strict priorty) First come first served algorithm (First come first served) TOS re-labeling Traffic Shaping (RTS)

Network management	SNMP v1/v2/v3 Telnet mode WEB interface Support for cluster management SSH support Supports fans, temperature, system logs, and hie rarchical alarms
Physical features
Power supply characteristics	Ac 110-240V adaptive,47-63Hz,1A/ 230V,1+1 RPS power hot backup Dc-48vdc /24VDC, supports cross power hot backup
Power	Up to 15W To prepare
Indicator light	Power indicator, system indicator, connection/transceiver finger in
Ambient temperature/humidity	Run at -40-85 ° C, save at -40-85 ° C,5-95%
